20 container
20” container

Fits 8

40 container
40” container

Fits 16

TCV
TCV

Fits 8

Articulated Lorry
Articulated Lorry

Fits 18

Wide bodied
Airline pallet

4 per PMC

Accepts
Accepts

EU/US pallet

System Tare
System Tare

365-410kg

Volumetric
Volumetric

450kg

Int. Payload
Int. Payload

1639 Litres

  • Solution overview
  • System Specifications
  • Evaluation Criteria
  • Documentation

Solution overview

The Evolution 1600 Tower Universal Pallet comes with unique pack-out options allowing for a multitude of different pharmaceutical packaging alternatives to be transported safely, simply and easily. It covers over 120-hour product protection for four product temperature ranges, including 2-8°C, 15-25°C, frozen (-25 to -15°C) and deep frozen (less -60°C) products, with the use of different PCM plates or dry ice.

The Evolution 1600 Tower Universal Pallet incorporates an integrated BLE/cellular Bluetooth data logger (compliant with RTCA DO 160G Part 21 H) along with a visible data display. It is specifically engineered to accommodate a wide range of data logging and IoT solutions readily accessible in the market.

Evolution 1600 available for 24-hour pick-up or delivery at all Centres of Excellence during 2025, available now for pre-order.

System Specifications

System Temp Range External Dimensions Internal Dimensions Tare Weight
Evolution 1600 -60°C to +25°C L 1440mm x W 1170mm x H 1600mm L 1230mm x W 1025mm x H 1300mm 350kg

Evaluation Criteria

  • Universal EU/US pallet (L1230 x W1025 x H1300mm internal space)
  • Internal payload 1639 litres
  • Best-in-class, accurate 120hr compliance time against ISTA 7D 24hr and product protection for <-60°C (in dry ice configuration), -20°C, +5°C and +20°C shipments
  • Fully integrated IOT system allowing for near real-time temperature monitoring of shipments, as well as asset management of the units
  • Engineered Composite construction giving superior product protection – ASTM4169 transit tested
  • Weight & Space efficient – class leading volumetric weight against similar solutions
  • Compatible with lower deck cargo of wide-bodied aircraft
  • No human intervention required during transit
  • Weather resistant, fully sealed system.
  • Robust. Reliable. Reusable design based on VIP composite construction.
  • Integrated BLE/cellular blue tooth data logger (RTCA DO 160G Part 21 H Compliant) and visible data display.
  • Visual checking of VIPs for assured performance
  • Double door access for ease of operation and to meet health and safety requirements
  • Customer visibility through Control Tower platform.
  • Unique QR identifier code facilitating return logistics.
  • One Way Lease options
  • Global availability through our global hub network within 24 hours or less
  • Fully recyclable and reusable solution
  • Global assurance, used by a wide range of pharmaceutical companies organisations
  • Low life-cycle cost of ownership due to longevity

Documentation

Evolution 1600 Tower Universal Pallet

The Tower Evolution1600 Universal is ideally suited for the transportation of:

Life Science Products:

  • Vaccines (including Covid 19 and ABIs)
  • Biotech products (Oncology, cardiovascular, etc)
  • Insulins
  • Active Pharmaceutical Ingredients (API)
  • Drug Substance
  • Semi-finished and finished products
  • Any other product requiring a stable temperature environment for transportation
Data Logger
Data Logger

Data loggers are built into all Tower containers, logging internal temperatures from -95°C (-139°F) up to 50°C (122°F). Users can get text or email notification of temperature excursions, as well as automatic data downloads throughout the transit (in-flight excluded) from loggers within range of the CX Gateway device. The loggers are built to FDA, USP, EU and WHO standards.

Product Testing
Product Testing

The Evolution 1600 Universal Double Pallet container is designed to be used all year round to all destinations using one packaging instruction – avoiding extra levels of complication and uncertainty within either validation or operational control.

Global Availability
Global Availability

Tower’s global network operates common processes and standards delivering consistency for customers. The network offers customers access to the complete range of Tower’s products with a local team of experts available to understand specific customer needs: this ensures that Tower delivers, where and when needed.

Circular Solution
Circular Solution

Tower cold chain recognise the role we play in working with our stakeholders to move from a linear supply chain to a circular one – providing a solution that supports our mutual ambition of waste reduction through reusability keeping our containers in use for longer reducing the need for disposal and recycling of temperature controlled packaging.
